Feed granulator

HKJ25C granulator
stamper inner diameter: φ250mm
pellet specification: φ1.5~φ8mm
main motor power: 22KW
output: 1~2t/h
feeding motor power: 0.75KW(frequency conversion)
Modulator motor power: 2.2KW

HKJ32 granulator
stamper inner diameter: φ320mm
pellet specification: φ2~φ8mm
main motor power: 37KW
output: 2~5t/h
feeding motor power: 0.75KW(frequency conversion)
Modulator motor power: 2.2KW
HKJ35 granulator
stamper inner diameter: φ350mm
pellet specification: φ2~φ8mm
main motor power: 2×30KW
output: 3~7t/h
feeding motor power: 1.5KW(frequency conversion)
Modulator motor power: 2.2KW


■ This model uses double motor SPB strong narrow belt transmission system, has ideal transmission efficiency, steady rotation, high output, low noise, no oil leak pollution, low maintenance cost;
■ This model has φ1.5-φ12mm many kinds of aperture and thickness link model; the user can willfully select according to different needs to obtain the best technology and economic efficiency;
■ Fixed stainless steel palletizing knife equipment, adjustment is more intuitionistic; Quick-discharge anchor ear link model, can match coordinated type pressure roller regulating mechanism and link mold hoisting equipment;
■ This model uses transducer control material feeding has over loading protection, outboard discharging mechanism.
■ Push-brace oil pump lubricating gear, quick and saving labor, safe and reliable, can realize to refuel without stopping engine;
■ Suitable for pelletization of high quality animal and poultry feed, aquatic feed and other materials.

HKJ series link model granulator
Model specification
HKJ35B
HKJ40B
HKJ45B
HKJ508
Main motor power(KW)
2x30
2x45
2x55
2x75
Modulator motor power(KW)
2.2x2
3x2
3x2
5.5x2
Output(t/h)
2~7
2~10
3~12
4~18
Link model diameter(MM)
φ350
φ400
φ450
φ508
Feeding motor power(KW)
1.5
1.5
1.5
1.5
Pellet specification(MM)
φ1.5~φ12
φ1.5~φ18
φ1.5~φ18
φ2~φ18
